Collaborative Palletizing Robot
CR50L-1900
50 kg collaborative palletizing workstation with 1,900 mm reach and a standard 500 mm lifting stroke.
Maximum payload
50 kg
Reach
1,900 mm
Axes
6
Repeatability
±0.1 mm
Technical specifications
CR50L-1900 specifications
Use these specifications for preliminary selection. Confirm the final configuration against product data, tooling load, center of gravity and line layout.
| Model | CR50L-1900 |
|---|---|
| Maximum payload | 50 kg |
| Reach | 1,900 mm |
| Axes | 6 |
| Palletizing height, including pallet | ≤2,300 mm |
| Repeatability | ±0.1 mm |
| Robot height | 1,800–2,800 mm |
| Lifting stroke | 500 mm standard; customizable |
| Pallet dimensions | 1,200 × 1,200 × 140 mm |
| Overall dimensions | 1,200 × 2,600 × 2,800 mm |
| Machine weight | 500 kg |
| Power supply capacity | 10 kVA |
Operating environment
Operating temperature
-15–55 °C
Relative humidity
20–80% RH, non-condensing
Permissible vibration
≤4.9 m/s²
Gas and liquid conditions
No flammable or corrosive gases or liquids
Water, oil and dust
Avoid contact with water, oil and dust
Electromagnetic environment
Keep away from electromagnetic interference sources
FAQ
Is CR50L-1900 suitable for my product?
Selection depends on product weight, dimensions, cycle time, pallet pattern, gripper type, reach, and site layout. Send product photos, dimensions, and target throughput for a model recommendation.
Can SCR Robot provide the complete automation cell?
Yes. The robot can be supplied as part of a complete automation solution including gripper, conveyor, pallet handling, guarding, PLC/HMI, and on-site layout planning.
Are the technical parameters final for every project?
The listed values come from the catalog model data. Final configuration should be confirmed against the exact tooling, payload center, working envelope, and production environment.
What information is needed for a quotation?
Please provide product photos, weight, size, packaging type, hourly output, pallet size if applicable, factory layout, voltage requirements, and destination country.
Check this model against your production line
Send product photos, weight, dimensions, target output, pallet or carton specifications and the available floor layout for configuration review.
